JJP36175 - Square D 175A 600V 3 Pole Molded Case Circuit Breaker J Frame

JJP36175

JJP36175 is a 175 amp, 600 volt, 3 pole molded case circuit breaker from Square D's J Frame series designed for reliable power distribution protection.This thermal magnetic circuit breaker features a current limiting design with long-time and instantaneous trip functions. It has a 65kA interrupting rating at 480VAC and supports both line and load side lug connections. The breaker is suitable for reverse fed applications and is UL, CSA, CE, and IEC certified. It mounts with a bolt-on or I-Line style plug-in connection and supports wire sizes from AWG 4 to AWG 4/0 aluminum or copper.

Key Specifications
• Amperage: 175A
• Voltage Rating: 600VAC, 250VDC
• Poles: 3
• Interrupting Rating: 65kA at 480VAC, 100AIC at 240VAC
• Frame Type: JJP (PowerPacT J Frame)
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Trip
• Mounting Type: Bolt-On / I-Line Style Plug-In
• Connection Type: Line & Load Side Lug Terminals
• Certifications: UL, CSA, CE, IEC, NOM, NEMA
• Wire Size Range: AWG 4 to AWG 4/0 Cu/Al
• Dimensions: Approx. 4.09" W x 3.4" D x 7.5" H
• Temperature Rating: -25 to 70 °C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JJP36175
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JJP
• Voltage : 600
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : J Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901660910
• GTIN : 00785901660910
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 4...AWG 4/0 aluminium/copper terminal
