JJL36150T - Square D Powerpact J 150 Amp 3 Pole 600 Volt Thermal Magnetic Circuit Breaker

JJL36150T

JJL36150T is a Square D Powerpact J series molded case circuit breaker designed for 150 Amp, 3 pole, 600 Volt applications with thermal magnetic trip unit.This circuit breaker features a unit mount lug connection, thermal magnetic trip technology with LI (Long-Time and Instantaneous) trip functions, and is suitable for overload and short-circuit protection. It has a breaking capacity code J with interrupt ratings of 100kA at 240VAC, 65kA at 480VAC, and 25kA at 600VAC. The breaker supports AWG 4 to 4/0 aluminum/copper wire gauge and is UL 489 listed with additional certifications including CE, CSA, IEC, CCC, and UKCA. The breaker measures 7.52" H x 4.12" W x 5" D and weighs approximately 5.29 lbs.

• Manufacturer: Square D
• Series/Frame: Powerpact J
• Amperage: 150 Amp
• Voltage Rating: 600 Volt AC
• Poles: 3
• Trip Unit: Thermal Magnetic with LI functions
• Mounting Type: Unit Mount Lug
• Interrupt Rating: 100kA @ 240VAC, 65kA @ 480VAC, 25kA @ 600VAC
• Wire Gauge Range: AWG 4 to 4/0 Aluminum/Copper
• Certifications: UL 489, CE, CSA, IEC, CCC, UKCA
• Dimensions (HxWxD): 7.52" x 4.12" x 5"
• Weight: 5.29 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JJL36150T
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JJL
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : J Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901760429
• GTIN : 00785901760429
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.3
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 4...AWG 4/0 aluminium/copper terminal
