JGL26200 - Square D 200 Amp 600 Volt 2 Pole PowerPact J Frame Circuit Breaker Thermal Magnetic Unit Mount

JGL26200

JGL26200 is a Square D PowerPact J Frame 2 pole circuit breaker rated for 200 Amps and 600 Volts, designed for reliable overcurrent protection.JGL26200 features thermal magnetic trip units with long-time and instantaneous functions, unit mounting type, and a high interrupting rating suitable for industrial applications. It supports line and load lug connections and complies with UL 489, CSA, IEC, CE, and CCC certifications.

Key Specifications
• Amperage: 200 Amps
• Voltage Rating: 600 VAC / 500 VDC
• Poles: 2 Pole
• Mounting Type: Unit Mount
• Interrupting Rating: 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 250 VDC and 500 VDC
• Frame Type: PowerPact J (JGL)
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous functions
• Terminal Connection: Line and Load Lugs
• Approvals: UL 489, CSA, IEC, CE, CCC
• Connection Type: Feed-Thru
• Wire Gauge: AWG 3/0, 350 kcmil Aluminum/Copper
• Dimensions (HxWxD): 7.52 x 4.12 x 5 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGL26200
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGL
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Line/Load Lug
• Frame Size : 250A/JG
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 3 AWG Max. Wire Size 350 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : Not Applicable

Product Data

• UPC : 785901433743
• GTIN : 00785901433743
• Country of Origin : Mexico
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.497
• Panel Type : I Line Panelboards
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
