JGA36250U31X - Square D 250A 600V 3P Molded Case Circuit Breaker, PowerPacT J Frame, I-Line Plug-In, Micrologic 3.2 Trip, 35kAIC @480V, UL/CSA/CE

JGA36250U31X

JGA36250U31X is a Square D molded case circuit breaker designed for reliable protection in commercial and industrial power distribution.

This 3-pole, 250A, 600VAC breaker features an I-Line plug-in mounting style, electronic Micrologic 3.2 trip unit with long-time and instantaneous (LI) protection, and is suitable for use in Class 611/612 I-Line panelboards. It offers high interrupting capacity, solid-state protection, and is mercury and PVC free for environmental compliance.

Key Specifications
• Amperage: 250A
• Voltage: 600VAC, 250/500VDC
• Poles: 3
• Mounting Type: I-Line plug-in
• Interrupt Rating: 35kAIC @480VAC, 65kAIC @240VAC, 18kAIC (see spec sheet)
• Series/Frame: PowerPacT J, JGA frame
• Trip Unit: Micrologic 3.2 standard, LI (long-time & instantaneous)
• Protection: Overload and short circuit, electronic solid-state
• Terminals: AWG 3/0 to 350 kcmil, aluminum/copper
• Certifications: UL, CSA, CE, NEMA, NOM, IEC, RoHS, REACH
• Actuator: Toggle
• Temperature Range: -25 to 70 °C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: JGA36250U31X
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGA
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Plug In Panelboard
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : G
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 3/0 AWG (Cu/Al) Max. Wire Size 350 kcmil (Cu/Al)
• Protection : Solid State

Product Data

• UPC : 785901965749
• GTIN : 00785901965749
• Country of Origin : Mexico
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 7.132
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
