JGA262001 - Square D 200A 600V 2-Pole I-Line Molded Case Circuit Breaker Thermal Magnetic

JGA262001

JGA262001 is a Square D molded case circuit breaker designed for reliable power distribution protection.This 2-pole circuit breaker features a 200 ampere rating and 600 volts AC voltage capacity. It uses a thermal-magnetic trip unit and is part of the PowerPact J-Frame series, compatible with I-Line panelboards and switchboards. The breaker has a high interrupt rating of 65kA at 240V AC, 35kA at 480V AC, and 18kA at 600V AC, ensuring robust fault current interruption. It is UL, CSA, and CE certified for safety and performance.

Key Specifications
• Amperage: 200 A
• Voltage Rating: 600 V AC
• Number of Poles: 2
• Mounting Type: I-Line
• Interrupt Rating: 65kA @ 240V AC, 35kA @ 480V AC, 18kA @ 600V AC
• Trip Unit: Thermal Magnetic
• Series/Frame: PowerPact J-Frame
• Certifications: UL, CSA, CE
• Type: Molded Case Circuit Breaker
• Current Limiting: Yes
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: JGA262001
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : JGA
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 250A/JG
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 3/0 AWG Max. Wire Size 300 MCM
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : AB



Product Data

• UPC : 785901431039
• GTIN : 00785901000000
• Country of Origin : United States
• Dimensions : 7.5 in (191 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Panel Type : I Line Panelboards
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 3/0...350 kcmil aluminium/copper terminals
