S29409 Schneider Electric Under Voltage Release Powerpact - Essential Electric Supply
S29409 - Schneider Electric PowerPact H/J/L Frame Undervoltage Trip 525-600V AC Circuit Breaker Accessory - Essential Electric Supply
Hover to zoom
S29409 Schneider Electric Under Voltage Release Powerpact - Essential Electric Supply
S29409 - Schneider Electric PowerPact H/J/L Frame Undervoltage Trip 525-600V AC Circuit Breaker Accessory - Essential Electric Supply

Reference images. Contact us for photos of the available unit.


Schneider Electric

S29409

Schneider Electric PowerPact H/J/L Frame Undervoltage Trip 525-600V AC Circuit Breaker Accessory

Voltage: 525-600VAC
Choose your condition
Compare New & Re-Certified

New
Original equipment manufacturer (OEM) products that have never been energized. New items may come in their original factory packaging or may be unused components removed from new panels. Packaging and cosmetic appearance can vary; contact our team for details or photos of the available unit.

Re-Certified
Original equipment manufacturer (OEM) products that have previously been energized and have been inspected, tested, and recertified for return to service. These items may show signs of prior use. Contact our team for details about the unit’s condition, testing documentation, and applicable warranty.

Ask about this part →
$144.31 $1,528.00
Save $1,383.69
Low inventory, please call (866) 377-3532 for stock check
View warranty coverage Return eligibility

Need it urgently? Call to confirm shipping options

Buying for a project? Request a quote

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

Product Description & Specifications

Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.

Manufacturer
Schneider Electric
Sub-Category
Under Voltage Release
Series
Powerpact
Frame
S
Voltage
525-600VAC
Country of origin
United States
Control Voltage Minimum
525
Compatible Frames
DG, DJ, DL, HD, HG, HJ, HL, HR, JD, JG, JJ, JL, JR, LD, LG, LJ, LL, LR
Control Voltate Maximum
600
GTIN
03295150294097
Dimensions
Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
Weight
1
Product description & additional details

S29409


S29409 is an undervoltage trip accessory designed for Schneider Electric PowerPact H, J, and L frame circuit breakers with a rated voltage of 525 to 600 V AC.This undervoltage trip unit provides remote trip capability by energizing trip coils from a separate voltage circuit. It features spring clamp connections for easy installation and is compatible with multiple PowerPact frame types, enhancing flexible system design.
  • Rated voltage: 525-600 V AC
  • Compatible with PowerPact H, J, and L frame circuit breakers
  • Undervoltage trip accessory type
  • Spring clamp connection for easy installation
  • Provides remote trip capability
  • Frame types supported: DG, DJ, DL, HD, HG, HJ, HL, HR, JD, JG, JJ, JL, JR, LD, LG, LJ, LL, LR
  • Country of origin: US
  • RoHS compliant and mercury free
  • Green Premium product
  • Discontinued product; no direct replacement
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: S29409
  • Manufacturer : Schneider Electric
  • Brand : Schneider Electric
  • Category : Circuit Breaker
  • Item Subcategory : Under Voltage Release
  • Family : Powerpact
  • Type : S
  • Voltage : 525-600VAC
  • Control Voltage Minimum : 525
  • Compatible Frames : DG, DJ, DL, HD, HG, HJ, HL, HR, JD, JG, JJ, JL, JR, LD, LG, LJ, LL, LR
  • Control Voltate Maximum : 600

Product Data

  • GTIN : 03295150294097
  • Country of Origin : United States
  • Dimensions : Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
  • Weight : 1

Technical Documents
Product Datasheet
Return eligibility: what to know before ordering

Return requests must be made within 30 days of shipping and require authorization. Used, installed, energized, or tested items are not eligible. A restocking fee of up to 35% may apply. Review the full policy before purchase.

Product-specific restrictions apply. International orders are non-cancellable and non-refundable under the policy.

Read the complete return and warranty policy ↗

Warranty supplied by Essential Electric

Warranty coverage is provided by Essential Electric, subject to the product and policy terms. Essential Electric is an independent supplier. Surplus or discontinued inventory may not qualify for the original manufacturer’s warranty.

Review coverage, exclusions, and the claim process ↗
