Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
JDM34250WU31X
JDM34250WU31X is a Schneider Electric PowerPacT J molded case circuit breaker designed for 250 ampere current and 3-pole configuration.This circuit breaker features a 480VAC voltage rating, 18kA interrupting capacity, and an I-Line bolt-on mounting connection with a Micrologic 3.2 trip unit providing advanced protection and energy management.
- Key Specifications
- Amperage: 250A
- Voltage: 480VAC / 277VAC
- Poles: 3
- Interrupt Rating: 18kA at 480VAC
- Mounting Type: I-Line bolt-on
- Series/Frame: PowerPacT J
- Trip Unit: Micrologic 3.2
- Continuous Current Rating: 80%
- Certifications: UL 489, CSA, NOM, IEC CCC, UKCA, CE
- Functions: Thermal magnetic trip unit, overcurrent protection
- Part Number: JDM34250WU31X
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Powerpact
- Type : JDM
- Voltage : 480
- Amperage : 250
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : J Frame
- Protection : Solid State
- Weight : 5
