HND312T36W - Eaton 1200A 600VAC 3-Pole Series C Molded Case Circuit Breaker with Digitrip 310 LSIG Trip

HND312T36W

HND312T36W is a 1200 Amp, 600 Volt, 3-pole molded case circuit breaker from Eaton's Series C NG-frame with Digitrip 310 electronic LSIG trip unit.This Eaton circuit breaker features a 65kA interrupt rating at 480VAC and 100kA at 240VAC, suitable for industrial panel mount applications. It is 80% rated, designed for 50/60 Hz operation, and complies with UL and CSA certifications. The breaker is without terminals and includes a rating plug for enhanced protection.

Key Specifications
• Amperage: 1200 A
• Voltage Rating: 600 VAC
• Poles: 3
• Interrupt Rating: 65 kA at 480 VAC, 100 kA at 240 VAC
• Frame: NG (N Frame)
• Series: Series C
• Trip Unit: Digitrip 310 LSIG Electronic
• Mounting Type: Panel Mount
• Frequency: 50/60 Hz
• Certifications: UL, CSA, HACR Rated
• Dimensions: 8.25 in W x 5.5 in D x 8.25 in H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HND312T36W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : HND
• Voltage : 600
• Amperage : 1200
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Frame Size : N Frame
• Protection : Solid State

Product Data

• UPC : 786679252789
• GTIN : 00786679252789
• Country of Origin : United States
• Dimensions : 5.5 in x 8.25 in x 8.25 in (Length/Depth x Height x Width)
• Weight : 52.05
• Certification : HACR Rated
