HLA36090 - Square D 90 Amp 600VAC 3 Pole PowerPacT H Frame Circuit Breaker I-Line Plug-In

HLA36090

HLA36090 is a 90 Amp, 600VAC, 3 Pole thermal magnetic molded case circuit breaker from Square D's PowerPacT H series.This circuit breaker features an I-Line style plug-in connection and a current limiting thermal magnetic trip unit with long-time and instantaneous trip functions. It has a 100kA interrupting rating at 480VAC and is suitable for use in panelboards and switchboards. The breaker supports wire sizes from AWG 14 to 3/0 aluminum or copper and is UL, CSA, CE, IEC, and NOM certified.

• Amperage: 90 Amps
• Voltage: 600VAC
• Poles: 3
• Series/Frame: PowerPacT H (HLA Frame)
• Mounting Type: I-Line Bracket Plug-In
• Interrupt Rating: 100kAIC at 480VAC
• Trip Unit: Thermal Magnetic with LI (Long-Time and Instantaneous)
• Connection Type: I-Line Style Plug-In
• Wire Gauge: AWG 14 to 3/0 Aluminum/Copper
• Certifications: UL, CSA, CE, IEC, NOM, NEMA, CCC, EAC
• Terminal Connection: Load Side Lug
• Operating Temperature: -25 to 70 °C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HLA36090
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HLA
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : I-Line, Lug
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 785901422259
• GTIN : 00785901422259
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
