HLA360256 - Square D 25 Amp 600V 3 Pole I-Line Molded Case Circuit Breaker

HLA360256

HLA360256 is a 25 Amp, 3 Pole, 600 Volt I-Line molded case circuit breaker from Square D designed for reliable circuit protection.This circuit breaker features a thermal magnetic trip unit with long-time and instantaneous protection. It is designed for plug-in mounting in I-Line panelboards and offers a high interrupt rating suitable for industrial and commercial applications. The breaker frame is HLA style, supporting 25 Amp current at up to 600 VAC. It provides robust protection with a 100kA interrupting capacity at 480V and is UL 489 listed.

Key Specifications
• Amperage: 25 Amp
• Voltage Rating: 600 VAC
• Poles: 3 Pole
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 100kA at 480V
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Frame/Series: HLA
• Certification: UL 489 Listed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: HLA360256
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HLA
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic



Product Data

• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
