HJL36035 - Square D 35 Amp 3 Pole 600V Thermal Magnetic Molded Case Circuit Breaker H Frame

HJL36035

HJL36035 is a 35 Amp, 3 pole thermal magnetic molded case circuit breaker from Square D designed for reliable overload and short circuit protection.This circuit breaker features a 600 Volt maximum rating with a current limiting thermal magnetic trip unit and an H frame series. It includes line and load lugs for bolt-on mounting and offers interrupt ratings of 100 kA at 240 VAC, 65 kA at 480 VAC, and 25 kA at 600 VAC. The breaker is UL, CSA, and CE certified, suitable for industrial and commercial applications.

• Amperage: 35 Amp
• Poles: 3
• Voltage Rating: 600 VAC max
• Interrupt Rating: 100 kA @ 240 VAC, 65 kA @ 480 VAC, 25 kA @ 600 VAC
• Trip Unit: Thermal Magnetic
• Mounting Type: Bolt-on
• Series/Frame: H Frame
• Terminal Type: Line and Load Lugs
• Approvals: UL, CSA, CE
• Dimensions: Approx. 4.12" W x 4.36" D x 6.4" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJL36035
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 35
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901458906
• GTIN : 00785901458906
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.145
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
