HJL26030 - Square D PowerPacT H 30A 2 Pole Circuit Breaker 600VAC 25kA Thermal Magnetic

HJL26030

HJL26030 is a Square D PowerPacT H series 2 pole molded case circuit breaker rated for 30A and 600VAC, featuring thermal magnetic protection and a 25kA interrupting rating at 600VAC. This breaker is designed for reliable circuit protection in commercial and industrial applications, with unit mount construction, feed-thru terminals, and long time plus instantaneous trip functions. It is suitable for reverse fed applications and features non-interchangeable trip units for added safety.

• Manufacturer: Square D
• Series/Frame: PowerPacT H
• Amperage: 30A
• Poles: 2
• Voltage Rating: 600VAC, 250VDC
• Interrupting Rating: 100kA@240VAC, 65kA@480VAC, 25kA@600VAC
• Mounting Type: Unit
• Connection Type: Feed-Thru, Line & Load Side Lug
• Protection Type: Thermal Magnetic
• Functions: Long Time and Instantaneous Trip
• Certifications: UL, CSA, CE, NEMA, IEC, RoHS
• Wire Gauge: AWG 14 to AWG 3/0 Aluminum/Copper

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJL26030
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJL
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901577935
• GTIN : 00785901577935
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.957
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
