HJA36150SN - Square D Powerpact H 150A 3 Pole 600V I-Line Plug-In Circuit Breaker with Shunt Trip

HJA36150SN

HJA36150SN is a Square D Powerpact H series molded case circuit breaker designed for industrial power distribution applications.This 3 pole, 150 amp breaker operates at 600 volts AC and features an I-Line style plug-in mounting with thermal magnetic trip unit and shunt trip function.Key Specifications

• Amperage: 150 A
• Voltage Rating: 600 V AC
• Poles: 3
• Mounting Type: I-Line plug-in
• Interrupt Rating: 25 kA at 600 VAC, 65 kA at 480 VAC
• Frame Type: Powerpact H
• Trip Unit: Thermal magnetic with long-time and instantaneous (LI) protection
• Continuous Current Rating: 80%
• Connection: I-Line style plug-in with lugs for load
• Control Type: Toggle with shunt trip
• Certifications: UL 489 Listed, CSA, NEMA, IEC, CE marked

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 12Vdc shunt trip

Specifications

• Part Number: HJA36150SN
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
