HJA36150SH - Square D PowerPact H 150A 600V 3-Pole Molded Case Circuit Breaker

HJA36150SH

HJA36150SH is a Square D PowerPact H series 3-pole molded case circuit breaker rated for 150 amperes at 600 volts with thermal-magnetic trip protection and I-Line style plug-in mounting. HJA36150SH delivers reliable power distribution performance with long-time and instantaneous trip functions, current-limiting capability, and suitability for reverse-fed applications in Class 612 I-Line panelboards and switchboards. This breaker features a non-interchangeable trip unit, toggle control, and is approved for use in demanding industrial and commercial environments.

• Amperage: 150A
• Voltage: 600/690VAC, 250VDC
• Poles: 3
• Phase: 3-phase
• Series: PowerPact H (H-Frame)
• Mounting Type: I-Line bracket plug-in
• Trip Unit: Thermal-magnetic with LI (Long-Time and Instantaneous) functions
• Interrupt Rating: 100kA at 240VAC, 65kA at 480VAC, 25kA at 600VAC
• Trip Setting: 900 to 1700 amperes
• Certifications: UL, CSA, CE, NEMA, NOM, IEC
• Connection: I-Line style with line and load lugs
• Continuous Current Rating: 80%

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 380/480Vac shunt trip

Specifications

• Part Number: HJA36150SH
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
