HJA36100YP - Square D 100A 600V 3-Pole I-Line Style Circuit Breaker 65kA@480V

HJA36100YP

HJA36100YP is a Square D 3-pole circuit breaker rated for 100 amps and 600 volts, designed for I-Line style plug-in mounting.This circuit breaker features a 65kA interrupting rating at 480V, suitable for heavy-duty power distribution applications. It provides reliable thermal-magnetic trip protection and is UL listed for safety and performance. The breaker is compatible with Square D Powerpact H series panels and offers current limiting capabilities.

• Amperage: 100A
• Voltage: 600V
• Poles: 3
• Mounting Type: I-Line plug-in
• Interrupt Rating: 65kA at 480V
• Series/Frame: Powerpact H
• Trip Unit: Thermal-magnetic
• UL Listed
• Current Limiting
• Manufacturer: Square D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA36100YP
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 606486282727
• GTIN : 03606486282724
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
