HJA36070UD - Square D Powerpact H-Frame 70A 600V 3 Pole Thermal Magnetic Circuit Breaker I-Line Plug-In

HJA36070UD

HJA36070UD is a Square D Powerpact H-Frame molded case circuit breaker designed for 3-phase electrical systems.

This circuit breaker features a 70 ampere rating with 600 volts AC maximum voltage and 3 poles. It uses a thermal magnetic trip unit with long-time and instantaneous trip functions, providing reliable overload and short circuit protection. The breaker has an interrupt rating of up to 65kA at 480V and 25kA at 600V, suitable for demanding industrial applications. It mounts via an I-Line plug-in style connection and supports wire sizes from AWG 14 to 3/0 aluminum or copper. The breaker is UL listed and designed for use in reverse fed applications with an 80% continuous current rating.

• Manufacturer: Square D
• Series/Frame: Powerpact H-Frame
• Amperage: 70 A
• Voltage: 600 VAC
• Poles: 3
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Interrupt Rating: 65 kA at 480V, 25 kA at 600V
• Mounting Type: I-Line Plug-In
• Wire Range: AWG 14 to 3/0 Aluminum/Copper
• Continuous Current Rating: 80%
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA36070UD
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
