HJA36070SR - Square D Powerpact H-Frame 70A 600V 3 Pole I-Line Thermal Magnetic Circuit Breaker

HJA36070SR

HJA36070SR is a Square D Powerpact H-Frame molded case circuit breaker with a 70 amp rating and 600 volt capacity designed for three-phase applications.This 3 pole circuit breaker features thermal magnetic trip technology, an 80% continuous current rating, and an I-Line plug-in mounting style suitable for I-Line panelboards. It offers a high interrupt rating of up to 65kA at 480V AC and 25kA at 600V AC, ensuring reliable current limiting and protection. The breaker supports ABC phase connection and is UL listed for safety and performance.

• Amperage: 70 A
• Voltage Rating: 600 VAC / 250 VDC
• Number of Poles: 3
• Mounting Type: I-Line plug-in
• Interrupt Rating: 65 kA at 480 VAC, 25 kA at 600 VAC
• Frame Type: H-Frame
• Trip Unit: Thermal Magnetic
• Continuous Current Rating: 80%
• Phase: 3
• Wire Range: AWG 14 to 3/0 aluminum/copper
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 125Vdc shunt trip

Specifications

• Part Number: HJA36070SR
• Manufacturer : Square D
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• Weight : 5
