HJA36040YP - Square D PowerPact H-Frame 3P 40A 600V I-Line Molded Case Circuit Breaker

HJA36040YP

HJA36040YP is a Square D PowerPact H-Frame molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This three-pole breaker features an I-Line plug-in mounting style, making it suitable for use in compatible switchgear and panelboards. The HJA36040YP provides thermal-magnetic trip protection with a rated current of 40A and a maximum voltage of 600V AC. It offers a short-circuit interrupting rating of 25kA at 600V AC, ensuring robust performance under fault conditions. The breaker is designed for ABC phase connection and is suitable for reverse-fed applications.

• Part Number: HJA36040YP
• Manufacturer: Square D
• Series/Frame: PowerPact H-Frame
• Poles: 3
• Rated Current: 40A
• Rated Voltage: 600V AC
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 25kA @ 600V AC
• Phase Connection: ABC
• Trip Unit: Thermal-Magnetic
• Protection Type: LI (Long-Time and Instantaneous)
• Standards: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA36040YP
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 606486282628
• GTIN : 03606490000000
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
