HJA260354 - Square D 35A 600V 2 Pole I-Line Style Molded Case Circuit Breaker

HJA260354

HJA260354 is a Square D 2 pole, 35 amp, 600 volt I-Line style molded case circuit breaker designed for reliable circuit protection.This PowerPact H series breaker features thermal magnetic trip units with a 65kA interrupting rating at 480V AC and 25kA at 600V AC. It is UL 489 listed and CSA, CE, IEC certified, suitable for use in panelboards and switchboards with I-Line plug-in mounting. The breaker supports phases B and C and is rated for 80% thermal capacity.

• Amperage: 35A
• Voltage: 600V AC
• Poles: 2
• Mounting Type: I-Line Style Plug-In
• Interrupt Rating: 65kA @ 480V, 25kA @ 600V
• Series/Frame: PowerPact H
• Trip Unit: Thermal Magnetic
• Certifications: UL 489, CSA, CE, IEC
• Phase: Single Phase (B & C)
• 80% Rated Thermal Capacity

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HJA260354
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HJA
• Voltage : 600
• Amperage : 35
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : H Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901539933
• GTIN : 00785901539933
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
