HHED63B125 - Siemens 125A 600V 3 Pole Molded Case Circuit Breaker Bolt-On

HHED63B125

HHED63B125 is a Siemens Sentron Series 3 pole molded case circuit breaker designed for reliable overcurrent protection in industrial and commercial power distribution systems. This breaker features a 125A current rating, 600VAC voltage rating, and a bolt-on mounting configuration for secure installation. It provides thermal magnetic protection with long time and instantaneous trip functions, ensuring robust circuit safety. The HHED63B125 is rated for 65kAIC at 480V, making it suitable for high-interrupting capacity applications. Load side lug terminals enhance connectivity and ease of installation. This circuit breaker is ideal for use in panelboards, switchboards, and industrial control panels where dependable protection and high performance are required. The HHED63B125 is part of the Siemens Sentron HHED frame series, known for durability and compliance with industry standards.

• Part Number: HHED63B125
• Manufacturer: Siemens
• Series: Sentron
• Frame Type: HHED
• Amperage: 125A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupting Rating: 65kAIC at 480V
• Protection Type: Thermal Magnetic
• Functions: Long Time and Instantaneous Trip
• Terminal Connection: Load Side Lug

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HHED63B125
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HHED
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643308169
• Weight : 7
