HHED63B025L - Siemens 25 Amp 3 Pole 600V Molded Case Circuit Breaker

HHED63B025L

HHED63B025L is a Siemens Sentron molded case circuit breaker designed for reliable overload and short circuit protection in industrial and commercial power distribution applications.

This thermal magnetic circuit breaker features a bolt-on mounting configuration and is rated for 25 amperes at 600 volts with 3 poles. The breaker delivers an 18 kiloamp interrupting rating at 600V and 65 kiloamp at 480V, meeting UL 489 and IEC 60947-2 standards. The HHED frame provides extra high breaking capacity with standard 40 degree C operation, making it suitable for demanding electrical systems requiring robust protection and reliable performance.

• Amperage Rating: 25 A
• Voltage Rating: 600 V
• Number of Poles: 3
• Mounting Type: Bolt-On
• Interrupting Rating: 18 kA at 600V, 65 kA at 480V
• Frame Size: HHED63
• Protection Type: Thermal Magnetic Overload and Short Circuit
• Certifications: UL 489, IEC 60947-2
• Dimensions: 6 in L x 4 in W x 8 in H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HHED63B025L
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : HHED
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 783643094840
• GTIN : 00783643094840
• Country of Origin : Mexico
• Weight : 4.079
• Certification : Ul Listed
• Wire Size : AWG 14 to AWG 10, Cu, AWG 12 to AWG 10, Al
