HGP36040 - Square D PowerPact H 40 Amp 3 Pole 600V Molded Case Circuit Breaker

HGP36040

HGP36040 is a 3 pole, 40 amp molded case circuit breaker rated for 600 VAC maximum voltage with thermal magnetic trip protection. This Square D PowerPact H frame breaker delivers reliable performance in industrial and commercial power distribution applications with multiple interrupt rating options depending on voltage level. HGP36040 features unit mount lug-lug construction, snap-in terminal design for easy conversion between busbar and lug options, and is suitable for panel mounting in distribution equipment. The breaker is UL 489 listed and meets CSA, NEMA, NMX, VDE, BS, CCC, IEC, and CE standards for global acceptance.

• Amperage: 40 Amp
• Voltage Rating: 600 VAC
• Poles: 3 Pole
• Frame Type: H Frame (PowerPact H)
• Trip Type: Thermal Magnetic
• Interrupt Rating: 18 kA at 600V, 35 kA at 480V, 65 kA at 240V
• Mounting: Unit Mount with Lugs
• Terminal Design: Snap-in with mechanical lug options
• Certifications: UL 489, CSA, NEMA, NMX, VDE, BS, CCC, IEC, CE marked

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HGP36040
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HGP
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901040552
• GTIN : 03606482463608
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
