HDP36080 - Square D 80A 600V 3 Pole Bolt-On Circuit Breaker PowerPact H Series

HDP36080

HDP36080 is a 3 pole, 80 amp, 600 volt bolt-on circuit breaker from Square D's PowerPact H Series.

This molded case circuit breaker features a thermal magnetic trip unit with long-time and instantaneous protection. It has an interrupt rating of 18kA at 480V AC, 14kA at 600V AC, and 25kA at 240V AC, suitable for a variety of industrial and commercial power distribution applications. The breaker is designed for bolt-on mounting and complies with industry standards for reliable circuit protection.

• Amperage: 80 Amps
• Voltage Rating: 600 Volts AC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 18kA @ 480V, 14kA @ 600V, 25kA @ 240V
• Series/Frame: PowerPact H
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Color: Black
• DC Voltage Rating: 250V DC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDP36080
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDP
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug, Terminal Nut
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.9
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
