HDP36070 - Square D 70A 600V 3 Pole Molded Case Circuit Breaker

HDP36070

HDP36070 is a 3 pole, 70 amp, 600 volt molded case circuit breaker from Square D's PowerPact H series, designed for reliable protection in commercial and industrial applications. This thermal magnetic breaker features a bolt-on mounting style and is built to meet the highest standards for safety and performance. It is mercury-free and PVC-free, making it suitable for environmentally sensitive installations. The HDP36070 is ideal for use in panelboards and switchgear requiring a robust, high-interrupting capacity solution.

• Part Number: HDP36070
• Manufacturer: Square D
• Series/Frame: PowerPact H
• Amperage: 70A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 18kA @ 480VAC, 14kA @ 600VAC
• Frame Type: HDP
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed, CSA Certified
• Features: Mercury Free, PVC Free

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDP36070
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDP
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug, Terminal Nut
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
