HDP36060 - Square D 60A 600VAC 3 Pole Thermal Magnetic Circuit Breaker PowerPact H Series

Save $3,282.55
SKU: HDP36060-New
Condition: New
Price:
$633.45 $3,916.00
Stock:
3 in stock
Limited availability — we'll confirm stock immediately after your order.

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

HDP36060 - Square D/ Schneider Electric Bolt-On 60 Amp 3 Pole Circuit Breaker - Essential Electric Supply
HDP36060 - Square D 60A 600VAC 3 Pole Thermal Magnetic Circuit Breaker PowerPact H Series - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
HDP36060 - Square D/ Schneider Electric Bolt-On 60 Amp 3 Pole Circuit Breaker - Essential Electric Supply
HDP36060 - Square D 60A 600VAC 3 Pole Thermal Magnetic Circuit Breaker PowerPact H Series - Essential Electric Supply

Description

HDP36060


HDP36060 is a Square D 3 pole, 60 amp, 600VAC thermal magnetic circuit breaker from the PowerPact H series designed for reliable circuit protection.This molded case circuit breaker features a unit mounting type with bolt-on connections, long time and instantaneous trip functions, and an interrupting rating of 14kA at 600VAC. It supports line and load side lug connections compatible with AWG 14 to AWG 3/0 aluminum or copper wire. Certified to UL, CSA, IEC, NEMA, CE, and other standards, it ensures compliance and safety in demanding electrical applications.
    Key Specifications
    • Manufacturer: Square D
    • Series/Frame: PowerPact H (HDP)
    • Amperage: 60 Amps
    • Voltage Rating: 600VAC
    • Poles: 3
    • Mounting Type: Unit Mount
    • Interrupting Rating: 14kA at 600VAC
    • Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
    • Connection Type: Bolt-On with Line and Load Side Lugs
    • Wire Gauge Range: AWG 14 to AWG 3/0 Aluminum/Copper
    • Certifications: UL, CSA, IEC, NEMA, CE, RoHS, CCC
    • Color: Black
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: HDP36060
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : HDP
  • Voltage : 600
  • Amperage : 60
  • Phase : 3
  • Poles : 3
  • AIC rating : 18kA@480V
  • Connection : Bolt-On
  • Functions : Long Time and Instantaneous Trip
  • Terminal Connection : Lug, Terminal Nut
  • Frame Size : H
  • Temp Rating : 28-158 °F (-2-70 °C)
  • MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
  • Protection : Thermal Magnetic

Product Data

  • Country of Origin : Mexico
  • Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
  • Weight : 4.9
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification : UL, CSA, NOM
  • Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
