HDP36040 - Square D 40A 600V 3 Pole Molded Case Circuit Breaker HDP Frame

HDP36040

HDP36040 is a 3 pole, 40 amp, 600 volt molded case circuit breaker from Square D designed for reliable circuit protection.This Square D HDP36040 circuit breaker features a thermal magnetic trip unit and is part of the HDP frame series. It has an interrupt rating of 18kA at 480V AC and 14kA at 600V AC, suitable for industrial and commercial applications. The breaker mounts with a bolt-on type for secure installation and meets industry certifications for safety and performance.

• Amperage: 40 Amps
• Voltage Rating: 600 VAC
• Number of Poles: 3
• Frame Type: HDP
• Interrupt Rating: 18kA @ 480V, 14kA @ 600V
• Trip Unit: Thermal Magnetic
• Mounting Type: Bolt-On
• Certifications: Industry Standard Safety Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDP36040
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDP
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug, Terminal Nut
• Frame Size : H
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.16
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
