HDL36030UA - Square D Powerpact H-Frame 30A 600V 3P Molded Case Circuit Breaker Thermal Magnetic

HDL36030UA

HDL36030UA is a Square D Powerpact H-Frame molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This 3-pole, 30A, 600V circuit breaker features a thermal magnetic trip unit with long-time and instantaneous protection, suitable for feed-thru and reverse fed applications. The unit mount design with line and load side lug terminals provides flexibility for installation in a variety of panel configurations. The HDL36030UA breaker is built to meet UL 489 standards and is rated for 18kA interrupting capacity at 480VAC. It is suitable for use in systems requiring robust protection and is compatible with Powerpact H-Frame enclosures. The breaker is designed for use with copper or aluminum conductors and offers a continuous current rating of 80%.

• Part Number: HDL36030UA
• Manufacturer: Square D
• Series: Powerpact H-Frame
• Poles: 3
• Amperage: 30A
• Voltage: 600VAC
• Mounting Type: Unit Mount
• Interrupt Rating: 18kAIC at 480VAC
• Protection Type: Thermal Magnetic
• Functions: LI - Long-Time and Instantaneous Trip
• Terminal Connection: Line and Load Side Lug
• Certifications: UL 489 Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDL36030UA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDL
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901757801
• GTIN : 00785901757801
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 4.5
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
