HDF36150 - Square D PowerPact H 150A 3-Pole 600V Molded Case Circuit Breaker

HDF36150

HDF36150 is a Square D PowerPact H series molded case circuit breaker rated for 150 amperes at 600 volts AC with three poles and thermal-magnetic trip protection. This unit mount breaker is designed for industrial and commercial power distribution applications requiring reliable overcurrent protection and fault interruption capability. The breaker features a D-frame size and is UL 489 listed for safety and performance compliance. Key Specifications

• Amperage Rating: 150A
• Voltage Rating: 600VAC (also rated 240VAC and 480VAC)
• Number of Poles: 3-Pole
• Frame Size: D
• Trip Type: Thermal-Magnetic
• Mounting: Unit Mount / Bolt-On
• Interrupt Rating: 25kA @ 240VAC, 18kA @ 480VAC, 14kA @ 600VAC
• Series: PowerPact H
• Certifications: UL 489, CSA Approved
• Frequency: 50/60 Hz
• Dimensions: 4.12 inches W x 4.36 inches D x 6.4 inches H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Lugs are not included

Specifications

• Part Number: HDF36150
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDF
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Busbar Connection
• Frame Size : H
• Temp Rating : 28-158 °F (-2-70 °C)
• MCM Size : Min. Wire Size 14 AWG (Cu/Al) Max. Wire Size 3/0 AWG (Cu/Al)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901824879
• GTIN : 00785901824879
• Country of Origin : United States
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.999
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
