HDA260904 - Square D 90 Amp 600 Volt 2 Pole PowerPact H I-Line Thermal Magnetic Circuit Breaker

HDA260904

HDA260904 is a Square D PowerPact H series molded case circuit breaker rated for 90 amps, 600 volts, and 2 poles with thermal magnetic trip unit.This circuit breaker features an I-Line plug-in mounting style, 14kA interrupt rating at 600 VAC, and is designed for single-phase applications. It offers 80% rated thermal magnetic trip protection with a BC trip curve, suitable for industrial and commercial power distribution. The breaker is UL listed and supports reverse fed applications.

• Amperage: 90 Amp
• Voltage: 600 VAC
• Poles: 2
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 14kA at 600 VAC
• Series/Frame: PowerPact H (HDA)
• Trip Unit: Thermal Magnetic, 80% rated, BC curve
• Phase: Single Phase (1PH)
• UL Listed
• Suitable for Reverse Fed Applications
• Non-Interchangeable Trip
• Manufacturer: Square D (Schneider Electric)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: HDA260904
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : HDA
• Voltage : 600
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : H Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 796474955037
• Country of Origin : Mexico
• Dimensions : 6.4 in (163 mm) x 4.09 in (104 mm) x 3.4 in (86 mm) (Height x Width x Depth)
• Weight : 3.001
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : AWG 14...AWG 3/0 aluminium/copper terminal
