Description
HBL9367
HBL9367 is a Hubbell industrial grade 50 amp, 250 volt, 2-pole, 3-wire grounding receptacle with a NEMA 6-50R configuration in black color.This heavy-duty receptacle features a thermoplastic/composite body with screw mounting hardware, designed for indoor dry environments. It supports a maximum continuous operating temperature of 75°C and withstands dielectric strength of 2,000 volts minimum. The device is back and side wired with screw terminals and accepts wire sizes from #12 AWG to #4 AWG. It is compliant with BABA Buy America standards and RoHS directives.
- Key Specifications
- Amperage: 50 A
- Voltage: 250 V
- Poles: 2-Pole
- Wires: 3-Wire Grounding
- Mounting Type: Screw Mount
- Material: Thermoplastic/Composite
- Dielectric Strength: 2,000 V minimum
- Operating Temperature: -40°C to 75°C
- Configuration: NEMA 6-50R
- Wire Size Range: #12 AWG to #4 AWG
- Certifications: BABA Compliant, RoHS
- Weight: 0.45 lb
- Part Number: HBL9367
- Manufacturer : Hubbell
- Brand : Hubbell
- Category : Conduit & Fittings
- Item Subcategory : Pin & Sleeve
- Voltage : 250 250
- UPC : 783585015279
- GTIN : 00783585015279
- Dimensions : 3.28 in H x 2.25 in W x 2.23 in D 3.28 x 2.25 x 2.23 in
- Weight : 0.3
