Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FD1020BP10
FD1020BP10 is a 20 amp, 1-pole molded case circuit breaker from Eaton's Series C with an F-frame design and fixed thermal, fixed magnetic trip unit.
This complete breaker is rated for 347 VAC and 125 VDC operation with a 35 kA interrupt rating at 277 VAC and 18 kA at 347 VAC. It features load-side terminals and is UL Listed for safety and reliability. The breaker operates at 50/60 Hz frequency and is designed for industrial and commercial electrical protection applications.
- Key Specifications
- Amperage Rating: 20 A
- Voltage Rating: 347 VAC, 125 VDC
- Number of Poles: Single-pole
- Frame Type: F-frame
- Series: Series C
- Trip Type: Fixed thermal, fixed magnetic
- Interrupt Rating: 35 kA at 277 VAC, 18 kA at 347 VAC
- Terminals: Load side
- Frequency Rating: 50/60 Hz
- Certifications: UL Listed
- Part Number: FD1020BP10
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 277
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 35kA@277V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
- UPC : 786679054611
- GTIN : 00786679054611
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 1.45
- Certification : UL Listed
