QO120PCAFI - Square D 20 Amp 1-Pole 120V AFCI Plug-On Neutral Circuit Breaker

QO120PCAFI

QO120PCAFI is a 20 Amp, 1-pole, 120 Volt Arc-Fault Circuit Interrupter (AFCI) breaker from Square D designed for plug-on neutral loadcenters.This combination AFCI circuit breaker features a plug-on neutral mounting type for easy installation without neutral pigtails. It has a 10,000 A interrupt rating (10 kAIC) and is UL listed and CSA certified, ensuring safety and reliability. Compatible exclusively with Square D QO plug-on neutral panels, it supports wire sizes from #14 to #8 AWG copper and aluminum. The breaker measures 4.8 inches in height, 0.75 inches in width, and 2.9 inches in depth.

Key Specifications
• Amperage: 20 Amps
• Voltage: 120 Volts AC
• Number of Poles: 1
• Mounting Type: Plug-on Neutral
• Interrupt Rating: 10,000 AIC
• Series/Frame: QO
• Trip Unit: Combination Arc-Fault Circuit Interrupter (AFCI)
• Certifications: UL Listed, CSA Certified
• Wire Size Range: #14-8 AWG Cu, #12-8 AWG Al
• Dimensions: 4.8" H x 0.75" W x 2.9" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QO120PCAFI
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QO SEries
• Type : QO
• Voltage : 120
• Amperage : 20
• Phase : 1
• Poles : 1
• AIC rating : 10kA@120V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901737186
• GTIN : 00785901737186
• Country of Origin : Mexico
• Dimensions : 4.8 in (121 mm) x 0.7 in (19 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.51
• Wire Size : AWG 14 to AWG 8, WG 12 to AWG 8, Copper/Aluminum
