EHD2020 - Cutler Hammer 20 Amp 2 Pole 480VAC Series C Molded Case Circuit Breaker

EHD2020

EHD2020 is a Cutler Hammer 20 Amp, 2 Pole molded case circuit breaker designed for reliable circuit protection.This Eaton Series C, F-frame breaker features a fixed thermal and magnetic trip unit, rated for 480VAC operation with a 14 kA interrupt rating. It is suitable for panelboard, switchboard, motor control center, and busway applications, meeting UL and CSA certifications.

Key Specifications
• Amperage: 20 Amps
• Voltage Rating: 480VAC
• Poles: 2
• Series/Frame: Eaton Series C, F-frame
• Trip Unit: Fixed thermal magnetic
• Interrupt Rating: 14 kA at 480VAC
• Mounting Type: Molded case
• Frequency: 50/60 Hz
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD2020
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Load Side Lug
• Frame Size : 100A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679317426
• GTIN : 00786679317426
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 2.9
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
