EDH3225Y - Eaton Series C 225A 3-Pole 240V Molded Case Circuit Breaker

EDH3225Y

EDH3225Y is an Eaton Series C complete molded case circuit breaker designed for reliable power distribution and circuit protection in industrial and commercial applications.

This F-frame molded case circuit breaker features a three-pole configuration with fixed thermal and fixed magnetic trip protection. The breaker is rated for 225 amperes at 240 Vac or 125 Vdc, with an interrupt rating of 100 kAIC at 240 Vac. It operates at frequencies between 50 to 60 Hz and includes line-side terminals for secure connections. The compact design measures 4.13 inches in width and depth with a total weight of 4.5 pounds, making it suitable for space-constrained installations.

• Amperage Rating: 225A
• Voltage Rating: 240 Vac, 125 Vdc
• Number of Poles: Three-pole
• Frame Type: F-frame
• Series: Series C
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 100 kAIC at 240 Vac
• Frequency Rating: 50 to 60 Hz
• Terminals: Line side
• Certifications: UL Listed
• Product Weight: 4.5 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH3225Y
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679454749
• GTIN : 00786679454749
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
