EDH3200 - Cutler Hammer 200A 240V 3-Pole F-Frame Molded Case Circuit Breaker Series C

EDH3200

EDH3200 is a Cutler Hammer Series C molded case circuit breaker designed for industrial applications.This 3-pole, 200 ampere breaker operates at 240 VAC and 125 VDC with a 100kA interrupt rating. It features a thermal magnetic trip unit, F-frame size, and bolt-on mounting. The breaker is UL and CSA certified and includes load lugs for easy installation. It is suitable for panel mounting and offers reliable protection with a fixed trip mechanism.

• Manufacturer: Cutler Hammer (Eaton)
• Series: C, F-Frame
• Amperage: 200A
• Voltage: 240 VAC, 125 VDC
• Poles: 3
• Interrupt Rating: 100kA at 240 VAC
• Trip Unit: Thermal Magnetic, Fixed Trip
• Mounting Type: Bolt-On / Panel Mount
• Certifications: UL, CSA, CE
• Load Lugs Included
• Dimensions: Approx. 4.125" W x 3.375" D x 6" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH3200
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 200
• Phase : 3
• Poles : 3
• AIC rating : 100kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679455166
• GTIN : 00786679455166
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
