Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDH3200YBP10
EDH3200YBP10 is a 200 amp, 3-pole Series C complete molded case circuit breaker from Eaton, designed for reliable circuit protection in electrical systems.This ED type circuit breaker features a fixed thermal magnetic trip unit and is rated for 240 Vac and 125 Vdc operation. It belongs to Eaton's F-frame Series C line, providing a 65 kA interrupt rating at 240 Vac. The breaker is UL listed and designed for load side terminals, suitable for use in a variety of commercial and industrial applications.
- Key Specifications
- Amperage Rating: 200 A
- Voltage Rating: 240 Vac, 125 Vdc
- Number of Poles: 3
- Series: Series C
- Frame: F
- Interrupt Rating: 65 kA at 240 Vac
- Trip Type: Fixed thermal magnetic
- Circuit Breaker Type: ED
- Terminals: Load side
- Certifications: UL Listed
- Frequency Rating: 50 to 60 Hz
- Part Number: EDH3200YBP10
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDH
- Voltage : 240
- Amperage : 200
- Phase : 3
- Poles : 3
- AIC rating : 100kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
- Weight : 4
