Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EDH3200Y
EDH3200Y is a Series C F-frame molded case circuit breaker designed for reliable protection in commercial and industrial applications. This three-pole breaker features a fixed thermal magnetic trip unit and is rated for 200A at 240VAC, making it suitable for a wide range of electrical systems. The EDH3200Y is built with a robust F-frame construction and offers a high interrupt rating of 100kAIC at 240VAC. It is designed for line and load terminal connections and operates within a frequency range of 50 to 60 Hz. The breaker is UL Listed and is part of Eaton's trusted Series C product line.
- Amperage Rating: 200 A
- Voltage Rating: 240 Vac, 125 Vdc
- Number of Poles: Three-pole
- Interrupt Rating: 100 kAIC at 240 Vac
- Frame: F
- Series: Series C
- Mounting Type: Line and load terminals
- Frequency Rating: 50 to 60 Hz
- Trip Type: Fixed thermal, fixed magnetic
- Certifications: UL Listed
Specifications
- Part Number: EDH3200Y
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EDH
- Voltage : 240
- Amperage : 200
- Phase : 3
- Poles : 3
- AIC rating : 100kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679454800
- GTIN : 00786679454800
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
