EDH3200L - Eaton 200A 240V 3-Pole Series C Molded Case Circuit Breaker 100kAIC

EDH3200L

EDH3200L is a three-pole molded case circuit breaker from Eaton's Series C line, designed for reliable protection in industrial and commercial power distribution systems. This breaker features a fixed thermal and fixed magnetic trip unit, providing consistent overcurrent protection for demanding applications. The unit is rated for 200 amperes and 240 volts AC, with a 100 kAIC interrupt rating at 240 Vac, making it suitable for a wide range of electrical environments. The breaker is equipped with lugs on both line and load sides for secure feed-thru connections. This Eaton Series C circuit breaker is built with an F-frame and is UL Listed for safety and compliance. The breaker is designed for three-phase systems and is ideal for use in panelboards and switchgear requiring dependable circuit protection.

• Part Number: EDH3200L
• Manufacturer: Eaton
• Series: Series C
• Frame: F
• Number of Poles: 3
• Amperage Rating: 200 A
• Voltage Rating: 240 Vac, 125 Vdc
• Interrupt Rating: 100 kAIC at 240 Vac
• Connection Type: Feed-Thru, Lugs on Line and Load
• Phase: 3
• Trip Type: Fixed Thermal, Fixed Magnetic
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDH3200L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDH
• Voltage : 240
• Amperage : 200
• Phase : 3
• Poles : 3
• AIC rating : 100kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679454442
• GTIN : 00786679454442
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
