EDB24110 - Square D 110 Amp 2 Pole 277/480V Bolt-On Thermal Magnetic Circuit Breaker

EDB24110

EDB24110 is a Square D 2 pole thermal magnetic circuit breaker rated for 110 amps and 277/480 volts AC with Bolt-On mounting.EDB24110 features a thermal magnetic trip unit with VISI-TRIP indication, designed for lighting panel board branch circuit protection. It has an interrupt rating of 18kA at 480 volts and is suitable for use in NF panelboard applications. The breaker is engineered for reliable performance at 40 degrees Celsius ambient temperature.

• Manufacturer: Square D
• Part Number: EDB24110
• Amperage: 110 Amps
• Poles: 2
• Voltage Rating: 277/480V AC
• Mounting Type: Bolt-On
• Interrupt Rating: 18kA @ 480V
• Trip Unit: Thermal Magnetic with VISI-TRIP
• Type/Series: EDB
• Application: Lighting Panel Board Branch Circuit

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB24110
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 480Y/277
• Amperage : 110
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 125A/EDB
• Temp Rating : 104 ¡F (40 ¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 785901129738
• GTIN : 00785901129738
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 2.436
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12, AWG 2/0 aluminium, AWG 14, AWG 2/0 copper
