EDB24035SA - Schneider Electric (Square D) 2-Pole 35 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

EDB24035SA

EDB24035SA is a 2-pole, 35A molded case circuit breaker with shunt trip from Schneider Electric.EDB24035SA is an E-Frame bolt-on circuit breaker rated for 480Y/277V AC with thermal-magnetic trip unit and shunt trip functionality, designed for Square D NF panelboards.

• Part Number: EDB24035SA
• Manufacturer: Schneider Electric
• Series/Frame: EDB E-Frame
• Amperage: 35A
• Voltage: 480Y/277V AC
• Poles: 2
• Mounting Type: Bolt-On
• Trip Unit: Thermal-Magnetic
• Interrupt Rating: 18kA@480Y/277V, 25kA@240V
• Shunt Trip: Yes

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: EDB24035SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 480Y/277
• Amperage : 35
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 606486143417
• GTIN : 03606486143414
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.17
• Standards : cULus, IEC
• Certification : cULus, IEC
