EDB24090SA - Schneider Electric (Square D) 2-Pole 90 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

EDB24090SA

EDB24090SA is a Schneider Electric E-Frame miniature circuit breaker with shunt trip, rated at 90A, 2-pole, for 480Y/277VAC systems.This bolt-on mounting breaker provides superior overload and short circuit protection in lighting panelboards and other applications. It features an 18kA interrupt rating at 480Y/277VAC and 25kA max at lower voltages, with a 125A frame size and thermal-magnetic trip unit.

• Part Number: EDB24090SA
• Manufacturer: Schneider Electric
• Amperage Rating: 90A
• Number of Poles: 2
• Voltage Rating: 480Y/277VAC
• Frame Size: E-Frame (125A max)
• Mounting Type: Bolt-On
• Interrupt Rating: 18kA at 480Y/277VAC
• Interrupt Rating: 25kA max at 240VAC
• Trip Unit: Thermal-Magnetic with Shunt Trip
• Series: EDB

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: EDB24090SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 480Y/277
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• GTIN : 00785901546702
• Country of Origin : United States
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.17
• Panel Type : NF panelboard
• Standards : cULus, IEC
• Certification : cULus, IEC
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
