EDB24070SA - Schneider Electric (Square D) 2-Pole 70 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

EDB24070SA

EDB24070SA - Schneider Electric E-Frame 2-pole miniature circuit breaker rated at 70A and 480Y/277V AC with shunt trip.EDB24070SA is a thermal-magnetic miniature circuit breaker designed for lighting panelboards, providing superior overload and short circuit protection with bolt-on mounting.

• Part Number: EDB24070SA
• Manufacturer: Schneider Electric
• Amperage Rating: 70A
• Voltage Rating: 480Y/277 VAC
• Number of Poles: 2
• Frame Size: E-Frame
• Mounting Type: Bolt-On
• Trip Unit: Thermal-Magnetic
• Interrupt Rating: 18kA at 480Y/277V AC, 25kA at 240V AC
• Protection Type: Overload, Short-Circuit

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

• Part Number: EDB24070SA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 480Y/277
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Frame Size : 125A/EDB
• Temp Rating : 104 ¡F (40 ¡C)
• MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
• Breaker Type : Shunt Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 785901487548
• GTIN : 00785901487548
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.17
• Panel Type : Square D NF Panelboards
• Standards : cULus, IEC
• Certification : cULus, IEC
