EDB24050SA - Schneider Electric (Square D) 2-Pole 50 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

Save $552.93
SKU: EDB24050SA-New
Condition: New
Price:
$738.07 $1,291.00
Stock:
2 in stock
Limited availability — we'll confirm stock immediately after your order.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

EDB24050SA - Schneider Electric/ Square D Bolt-On 50 Amp 2 Pole Circuit Breaker - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
EDB24050SA - Schneider Electric/ Square D Bolt-On 50 Amp 2 Pole Circuit Breaker - Essential Electric Supply

Description

EDB24050SA


EDB24050SA is a Type EDB miniature circuit breaker from Schneider Electric (Square D) designed for lighting panelboards, offering superior overload and short circuit protection in a compact E-Frame format. This 50-ampere, 2-pole breaker operates at 480Y/277 VAC and features a bolt-on mounting configuration with factory-installed shunt trip for remote tripping via external control. The breaker utilizes aluminum lug terminals compatible with 12 to 2/0 AWG wire and employs a thermal-magnetic trip unit with a trip current rating of 1800A and hold current of 630A.
  • Amperage Rating: 50A
  • Number of Poles: 2
  • Voltage Rating: 480Y/277 VAC
  • Interrupt Rating: 25kA at 240 VAC, 18kA at 480Y/277 VAC, 25kA at 120 VAC
  • Series/Frame: Type EDB E-Frame
  • Trip Unit: Thermal-Magnetic
  • Mounting: Bolt-on
  • Terminal Type: Aluminum Lugs
  • Wire Compatibility: 12 to 2/0 AWG
  • Special Features: Shunt Trip, Signal Indicator
  • Certifications: UL Listed, HACR Rated, TAA Compliant
  • Country of Origin: Mexico
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip


Specifications

  • Part Number: EDB24050SA
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : EDB Series
  • Type : EDB
  • Voltage : 480Y/277
  • Amperage : 50
  • Phase : 1
  • Poles : 2
  • AIC rating : 18kA@480V
  • Connection : Bolt-On
  • Functions : Long-Time and Instantaneous Trip
  • Terminal Connection : Lug
  • Frame Size : 125A/EDB
  • Temp Rating : 104 ¡F (40 ¡C)
  • MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 6 AWG
  • Breaker Type : Shunt Trip
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901545828
  • GTIN : 00785901545828
  • Country of Origin : Mexico
  • Dimensions : 5.66 in (143.76 mm) x 1.96 in (49.78 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
  • Weight : 3.17
  • Panel Type : Square D NF Panelboards
  • Standards : cULus, IEC
  • Certification : cULus, IEC
  • Wire Size : AWG 12 to AWG 2/0, Aluminum, AWG 14 to AWG 2/0, Copper
