EDB24045SA - Schneider Electric (Square D) 2-Pole 45 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB

Name: EDB24045SA - Schneider Electric (Square D) 2-Pole 45 A 480Y/277 V AC Bolt-On Circuit Breaker with Shunt Trip, Type EDB
Brand: Square D
SKU: EDB24045SA-ReCert
Price: 436.87 USD
Availability: InStock

SKU: EDB24045SA-ReCert

Condition: Re-Certified

Variant

Price:

$436.87

Stock:

Low inventory, please call for stock check
This ships in 1-2 business days

Quantity:

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

Enter your ZIP code:

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Manufacturer:Schneider Electric
Sub-Category:Molded Case

EDB24045SA - Schneider Electric/ Square D Bolt-On 45 Amp 2 Pole Circuit Breaker - Essential Electric Supply

Roll over image to zoom in Click on image to zoom Images are for reference only

EDB24045SA

EDB24045SA - Schneider Electric E-Frame mini circuit breaker, 45A, 2 pole, 480Y/277VAC, bolt-on mounting with shunt trip.This Schneider Electric EDB24045SA is a molded case mini circuit breaker from the EDB series with E-Frame design, featuring thermal-magnetic trip protection and a shunt trip mechanism for remote operation. It provides reliable overload and short-circuit protection for use in Square D NF panelboards, with bolt-on mounting and trip indicator.

Part Number: EDB24045SA
Manufacturer: Schneider Electric
Series/Frame: EDB / E-Frame
Amperage: 45A
Poles: 2
Voltage: 480Y/277VAC
Mounting Type: Bolt-On
Trip Unit: Thermal-Magnetic
Interrupt Rating: 25kA max
Product Destination: Square D NF Panelboard

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with 120V shunt trip

Specifications

Part Number: EDB24045SA
Manufacturer : Schneider Electric
Brand : Square D
Category : Circuit Breaker
Item Subcategory : Molded Case
Family : EDB Series
Type : EDB
Voltage : 480Y/277
Amperage : 45
Phase : 1
Poles : 2
AIC rating : 18kA@480V
Connection : Bolt-On
Functions : LI - Long-Time and Instantaneous
Terminal Connection : Lug
Temp Rating : 104 ¡F (40 ¡C)
Protection : Thermal Magnetic

Product Data

Country of Origin : Mexico
Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
Weight : 2
Standards : cULus, IEC
Certification : cULus, IEC

Accesories

Part	Manufacture	Sub Category
HPAFD	Square D	Parts & Accessories
