Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
ED3030
ED3030 is a Westinghouse 3-pole, 30 amp bolt-on circuit breaker designed for 240V applications with a high interrupt rating.ED3030 features thermal magnetic trip protection and is built on the Series C frame, providing reliable circuit protection for low voltage systems. It supports 240VAC and 125VDC operation and offers a 65kA interrupting rating at 240V, ensuring robust short circuit and overload protection.
- Manufacturer: Westinghouse
- Amperage: 30 Amps
- Voltage: 240 VAC, 125 VDC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 65,000 AIC @ 240V
- Trip Unit: Thermal Magnetic
- Series/Frame: Series C
Specifications
- Part Number: ED3030
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : ED
- Voltage : 240
- Amperage : 30
- Phase : 3
- Poles : 3
- AIC rating : 65kA@240V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Frame Size : F Frame
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 782116349067
- GTIN : 00782116349067
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
