CV2150XMM - Cutler Hammer Eaton 150A 120/240V Two-Pole Molded Case Circuit Breaker CV Frame 65kAIC Bolt-On

CV2150XMM

CV2150XMM is a Cutler Hammer Eaton Type CV molded case circuit breaker rated for 150 amps and 120/240 volts with two poles and a 65 kA interrupt rating.This circuit breaker features a thermal magnetic trip unit and bolt-on mounting type. It supports wire sizes from #6 to 4/0 AWG copper or aluminum and terminals up to #4/0 kcmil maximum load. The breaker includes a mounting kit and meets UL 489 and CSA Std. C22.2 No. 5 certifications.

• Amperage Rating: 150 A
• Voltage Rating: 120/240 V AC
• Number of Poles: Two-pole
• Interrupt Rating: 65 kAIC
• Frame Type: CV
• Trip Unit: Thermal Magnetic
• Mounting Type: Bolt-On
• Wire Size: #6-4/0 AWG Cu/Al
• Terminal Capacity: #4/0 kcmil maximum
• Includes Mounting Kit
• Certifications: UL 489, CSA Std. C22.2 No. 5
• Weight: 2.75 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CV2150XMM
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CV Series
• Type : CV
• Voltage : 240
• Amperage : 150
• Phase : 1
• Poles : 2
• AIC rating : 65kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786685706467
• GTIN : 00786685706467
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 2.75
• Certification : UL 489; CSA Standard; C22.2 No. 5
