BQC230230 - Eaton Cutler Hammer 30A 240V 4-Pole Quadplex Circuit Breaker Common Trip

BQC230230

BQC230230 - Eaton Type BQC quadplex circuit breaker, rated at 120/240V, 30/30 Amp, 2-pole/2-pole configuration for residential panelboards.This plug-on mount CTL quadplex breaker occupies two 1-inch spaces and provides four separate circuits with outer poles common trip and center poles common trip. It features thermal magnetic trip mechanism, rejection tab for compatibility, and 10 kAIC interrupt rating at 120VAC.

• Part Number: BQC230230
• Manufacturer: Eaton
• Amperage: 30/30 Amp
• Voltage: 120/240 V
• Poles: 2 Pole/2 Pole Quadplex
• Frame: BQC
• Mounting Type: Plug-On
• Interrupt Rating: 10 kA @ 120VAC
• Trip Type: Common/Thermal Magnetic
• Category: Residential Circuit Breaker

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQC230230
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQC
• Voltage : 240
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 786676371896
• GTIN : 00786676371896
• Country of Origin : United States
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.9
• Standards : HACR Rated, UL Listed
• Certification : UL 489,Federal Specifications Classification W-C399
• Wire Size : AWG 14 to AWG 4, Cu/Al
