BQC230215 - Cutler Hammer 2 Pole 30 Amp 120/240V Circuit Breaker BQC Series

BQC230215

BQC230215 is a Cutler Hammer 2 pole circuit breaker designed for 120/240V applications with a 30 amp rating.This BQC series circuit breaker features a 1-inch CTL plug-on mounting type with a common trip mechanism and a 10 kA interrupting rating. It is a thermal magnetic breaker compatible with BR series load centers, including a rejection tab feature for proper installation. The breaker is UL listed and CSA certified for safety and reliability.

• Manufacturer: Cutler Hammer (Eaton)
• Part Number: BQC230215
• Amperage: 30 Amps
• Voltage: 120/240 VAC
• Poles: 2
• Mounting Type: 1-Inch CTL Plug-On
• Interrupting Rating: 10 kAIC
• Series/Frame: BQC
• Trip Unit: Thermal Magnetic
• Common Trip: Yes
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQC230215
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQC
• Voltage : 240
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 786676006163
• GTIN : 00786676006163
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.9
• Standards : HACR Rated, UL Listed
• Certification : UL 489,Federal Specifications Classification W-C397
• Wire Size : AWG 14 to AWG 4, Cu/Al
