BQC2302120 - Cutler Hammer Eaton 4-Pole 120/240V 20A/30A Quadplex Circuit Breaker Plug-On 10kAIC

BQC2302120

BQC2302120 - Eaton Type BQC quadplex circuit breaker with (2) 20 A single-pole and (1) 30 A two-pole configuration for residential loadcenters.

This thermal magnetic breaker features common trip, plug-on mounting, rejection tab, and 1-inch CTL design for Type BR loadcenters. It supports #14-4 AWG Cu/Al wire and provides reliable protection at 120/240 V with 10 kAIC interrupt rating across four poles.

Key Specifications

• Circuit Breaker Type: BR thermal magnetic
• Type: BQC quadplex, 1-inch CTL plug-on
• Poles: 4
• Amperage: (2) 20 A single-pole, (1) 30 A two-pole
• Voltage Rating: 120/240 V AC
• Interrupt Rating: 10 kAIC
• Trip Type: Common/Thermal magnetic
• Mounting: Plug-on
• Wire Size: #14-4 AWG Cu/Al
• Special Features: Rejection tab
• Used With: Type BR loadcenters
• Certifications: UL 489

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQC2302120
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQC
• Voltage : 240
• Amperage : 30
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 786676371780
• GTIN : 00786676371780
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.9
• Standards : HACR Rated, UL Listed
• Certification : UL 489,Federal Specifications Classification W-C395
• Wire Size : AWG 14 to AWG 4, Cu/Al
