BQC230220 - Cutler Hammer 120/240V 4 Pole 30A/20A Thermal Magnetic Circuit Breaker Plug-In

BQC230220

BQC230220 - Eaton BR thermal magnetic quadplex circuit breaker with one 20A two-pole and one 30A two-pole configuration, plug-on mount, and common trip.Type BQC 1-inch CTL plug-on circuit breaker designed for Type BR loadcenters, featuring rejection tab and thermal-magnetic trip mechanism for reliable overcurrent protection in residential and light commercial applications.

• Amperage Rating: (1) Two-Pole 20A, (1) Two-Pole 30A
• Voltage Rating: 120/240V
• Number of Poles: 4
• Mounting Type: Plug-on
• Interrupt Rating: 10 kAIC
• Series/Frame: BQC
• Trip Type: Thermal-magnetic, common trip
• Wire Size: #14-4 AWG Cu/Al
• Certifications: UL 489
• Special Features: Rejection tab, HACR rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: BQC230220
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : BQ Series
• Type : BQC
• Voltage : 240
• Amperage : 30
• Phase : 1
• Poles : 2
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Lug
• Protection : Thermal Magnetic

Product Data

• UPC : 786676006170
• GTIN : 00786676006170
• Country of Origin : Dominican Republic
• Dimensions : 3 in x 3 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.9
• Standards : HACR Rated, UL Listed
• Certification : UL 489,Federal Specifications Classification W-C398
• Wire Size : AWG 14 to AWG 4, Cu/Al
